Improving visual quality of a photo of a document

There is possibility that you do not have scanner at the moment and you made a photo of a document with your camera. Here is a small program how you can improve the photo especially if there is nonuniform light and shadows. I found the key idea in the blog of ABBY company (of course, they use much more advanced method).
initial =
  ImageAdjust@
   ColorConvert[
    Import["http://habrastorage.org/files/76b/906/3d8/\
76b9063d8b9f44aebbb0411f7e51e46c.jpg"], "Grayscale"];
image = ColorNegate@WienerFilter[initial, denoising];
[url=]
We need to define five parameters:
denoising = 1;
enhancement = {4, 3};
smoothing = True;

scale = 30;
gamma = 3
The first three are not important, but the last two are used for local contrast adjustment:
idata1 = Developer`ToPackedArray@ImageData[initial];
idata2 = Developer`ToPackedArray@
   ImageData[MeanFilter[initial, scale]];

idata2 = If[Min[idata2] > 0, idata2,
   Module[{min = Union[Join @@ idata2][[2]]},
    Map[Max[#, min] &, idata2, {2}]]];
The idea is to remove shadows by using local gamma-correction:
localContrast =
  ColorNegate@WienerFilter[Image[(idata1/idata2)^gamma], denoising];

mask = If[smoothing, Erosion[Dilation[Binarize[localContrast], 2], 1],
    Binarize[localContrast]];
Then one can use the mask to subtract background by inpainting:
 background =
   Inpaint[ImageMultiply[image, ColorNegate@mask], mask ,
    Method -> "NavierStokes"];

 backgroundSubtracted =
   ImageSubtract[ImageMultiply[image, mask],
    ImageMultiply[background, mask]];

 result = ColorNegate@
   ImageMultiply[
    ImageMultiply[backgroundSubtracted, enhancement[[1]]],
    ImageMultiply[localContrast, enhancement[[2]]]];
That is it.

Of course, you can delete large artefacts “by hands”.
largecomponents =
  ImageMultiply[
   GaussianFilter[
    DeleteSmallComponents[Binarize[ColorNegate@result, 0.1], 3000],
    10], 4];

ColorNegate@
ImageMultiply[ColorNegate@result, ColorNegate@largecomponents]
POSTED BY: Grisha Kirilin
Hi Grisha,

Good tip!!

Thanks.
By the way I posted I question about improving a pic, would you have any suggestion?

I will appreciate.

http://community.wolfram.com/groups/-/m/t/223724?p_p_auth=qniT6LXf
POSTED BY: Marcelo De Cicco
