[EIWL] Solving Example 6.10 of the Stephen Wolfram book

Posted 9 years ago

Hi all.

I am working my way through the exercises on this page:

https://www.wolfram.com/language/elementary-introduction/06-making-tables.html

However I am stuck on Q. 6.10: Make a list line plot of the first digits of the first 100 squares.

IntegerDigits[Range[100]^2]

results in:

    {{1},{4},{9},{1,6},{2,5},{3,6},{4,9},{6,4},{8,1},{1,0,0},{1,2,1},{1,4,4},{1,6,9},{1,9,6},{2,2,5},{2,5,6},{2,8,9},{3,2,4},{3,6,1},{4,0,0},{4,4,1},{4,8,4},{5,2,9},

{5,7,6},{6,2,5},{6,7,6},{7,2,9},{7,8,4},{8,4,1},{9,0,0},{9,6,1},{1,0,2,4},{1,0,8,9},{1,1,5,6},{1,2,2,5},{1,2,9,6},{1,3,6,9},{1,4,4,4},{1,5,2,1},{1,6,0,0},{1,6,8,1},

{1,7,6,4},{1,8,4,9},{1,9,3,6},{2,0,2,5},{2,1,1,6},{2,2,0,9},{2,3,0,4},{2,4,0,1},{2,5,0,0},{2,6,0,1},{2,7,0,4},{2,8,0,9},{2,9,1,6},{3,0,2,5},{3,1,3,6},{3,2,4,9},

{3,3,6,4},{3,4,8,1},{3,6,0,0},{3,7,2,1},{3,8,4,4},{3,9,6,9},{4,0,9,6},{4,2,2,5},{4,3,5,6},{4,4,8,9},{4,6,2,4},{4,7,6,1},{4,9,0,0},{5,0,4,1},{5,1,8,4},{5,3,2,9},

{5,4,7,6},{5,6,2,5},{5,7,7,6},{5,9,2,9},{6,0,8,4},{6,2,4,1},{6,4,0,0},{6,5,6,1},{6,7,2,4},{6,8,8,9},{7,0,5,6},{7,2,2,5},{7,3,9,6},{7,5,6,9},{7,7,4,4},{7,9,2,1},

{8,1,0,0},{8,2,8,1},{8,4,6,4},{8,6,4,9},{8,8,3,6},{9,0,2,5},{9,2,1,6},{9,4,0,9},{9,6,0,4},{9,8,0,1},{1,0,0,0,0}}

Now I would like to count the length of individual elements in the above list ie. {1,1,1,2,2,2,2,2,2,3,3,3....}. But how?

Thanks in advance.

D

EDIT: This is not homework. I am self-learning Mathematica, and will be doing all the exercises in all 47 Chapters, which will probably take me a few weeks to a few months. Hence you may see me asking lots of questions in this forum! :)

POSTED BY: D P
18 Replies

Hi D.P.,

I'm working through the EIWL exercises myself, and am currently at Chp. 9. I remember this problem and came up with this solution, also using only the functions we've been taught so far in the book:

ListLinePlot[Table[First[IntegerDigits[n^2]], {n, 100}]]

The tasks defined in the exercises range from being enormously simple to just maddening, but I keep telling myself that this is just how it will be once I know enough to start applying the WL to real problems. And I've accepted that the repetition (yet another problem built around Table and IntegerDigits?) is all for the best.

By the way, I don't know if you're working off the web page or the MMA notebooks of EIWL, but I just found out that the downloadable MMA notebooks come with additional exercises in each chapter and also give you a way to enter and check your output (note: not your solution) against the expected answer directly in a notebook. This rather belated discovery has made working through EIWL much more enjoyable (even, yes, fun!).

POSTED BY: Arno Bosse

There are a lot of approaches to solve Problem 6.10

Make a list line plot of the first digits of the first 100 squares.

But, we must use only the functions exposed in the first 6 chapters. So...

We can generate a list of the first 100 squares:

In[1]:= Table[i^2, {i, 100}]

Out[1]= {1, 4, 9, 16, 25, 36, 49, 64, 81, 100, 121, 144, 169, 196, \
225, 256, 289, 324, 361, 400, 441, 484, 529, 576, 625, 676, 729, 784, \
841, 900, 961, 1024, 1089, 1156, 1225, 1296, 1369, 1444, 1521, 1600, \
1681, 1764, 1849, 1936, 2025, 2116, 2209, 2304, 2401, 2500, 2601, \
2704, 2809, 2916, 3025, 3136, 3249, 3364, 3481, 3600, 3721, 3844, \
3969, 4096, 4225, 4356, 4489, 4624, 4761, 4900, 5041, 5184, 5329, \
5476, 5625, 5776, 5929, 6084, 6241, 6400, 6561, 6724, 6889, 7056, \
7225, 7396, 7569, 7744, 7921, 8100, 8281, 8464, 8649, 8836, 9025, \
9216, 9409, 9604, 9801, 10000}

In this list, we must find the digits of each number:

In[39]:= IntegerDigits@Table[i^2, {i, 100}]

Out[39]= {{1}, {4}, {9}, {1, 6}, {2, 5}, {3, 6}, {4, 9}, {6, 4}, {8,
  1}, {1, 0, 0}, {1, 2, 1}, {1, 4, 4}, {1, 6, 9}, {1, 9, 6}, {2, 2,
  5}, {2, 5, 6}, {2, 8, 9}, {3, 2, 4}, {3, 6, 1}, {4, 0, 0}, {4, 4,
  1}, {4, 8, 4}, {5, 2, 9}, {5, 7, 6}, {6, 2, 5}, {6, 7, 6}, {7, 2,
  9}, {7, 8, 4}, {8, 4, 1}, {9, 0, 0}, {9, 6, 1}, {1, 0, 2, 4}, {1, 0,
   8, 9}, {1, 1, 5, 6}, {1, 2, 2, 5}, {1, 2, 9, 6}, {1, 3, 6, 9}, {1,
  4, 4, 4}, {1, 5, 2, 1}, {1, 6, 0, 0}, {1, 6, 8, 1}, {1, 7, 6,
  4}, {1, 8, 4, 9}, {1, 9, 3, 6}, {2, 0, 2, 5}, {2, 1, 1, 6}, {2, 2,
  0, 9}, {2, 3, 0, 4}, {2, 4, 0, 1}, {2, 5, 0, 0}, {2, 6, 0, 1}, {2,
  7, 0, 4}, {2, 8, 0, 9}, {2, 9, 1, 6}, {3, 0, 2, 5}, {3, 1, 3,
  6}, {3, 2, 4, 9}, {3, 3, 6, 4}, {3, 4, 8, 1}, {3, 6, 0, 0}, {3, 7,
  2, 1}, {3, 8, 4, 4}, {3, 9, 6, 9}, {4, 0, 9, 6}, {4, 2, 2, 5}, {4,
  3, 5, 6}, {4, 4, 8, 9}, {4, 6, 2, 4}, {4, 7, 6, 1}, {4, 9, 0,
  0}, {5, 0, 4, 1}, {5, 1, 8, 4}, {5, 3, 2, 9}, {5, 4, 7, 6}, {5, 6,
  2, 5}, {5, 7, 7, 6}, {5, 9, 2, 9}, {6, 0, 8, 4}, {6, 2, 4, 1}, {6,
  4, 0, 0}, {6, 5, 6, 1}, {6, 7, 2, 4}, {6, 8, 8, 9}, {7, 0, 5,
  6}, {7, 2, 2, 5}, {7, 3, 9, 6}, {7, 5, 6, 9}, {7, 7, 4, 4}, {7, 9,
  2, 1}, {8, 1, 0, 0}, {8, 2, 8, 1}, {8, 4, 6, 4}, {8, 6, 4, 9}, {8,
  8, 3, 6}, {9, 0, 2, 5}, {9, 2, 1, 6}, {9, 4, 0, 9}, {9, 6, 0,
  4}, {9, 8, 0, 1}, {1, 0, 0, 0, 0}}

We can generate a list of the first digits in each sub-list by different means. But, the beginner knows at this point only a few possibilities. First, we must identify every sub-list and its first element. For this, we use functions Part[] and First[]. Second, to generate a list, we use function Table[]:

In[43]:= Table[
 First@Part[IntegerDigits@Table[i^2, {i, 100}], j], {j, 100}]

Out[43]= {1, 4, 9, 1, 2, 3, 4, 6, 8, 1, 1, 1, 1, 1, 2, 2, 2, 3, 3, 4, \
4, 4, 5, 5, 6, 6, 7, 7, 8, 9, 9, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, \
1, 2, 2, 2, 2, 2, 2, 2, 2, 2, 2, 3, 3, 3, 3, 3, 3, 3, 3, 3, 4, 4, 4, \
4, 4, 4, 4, 5, 5, 5, 5, 5, 5, 5, 6, 6, 6, 6, 6, 6, 7, 7, 7, 7, 7, 7, \
8, 8, 8, 8, 8, 9, 9, 9, 9, 9, 1}

And finally, we can use ListLinePlot[]:

ListLinePlot[
 Table[First@Part[IntegerDigits@Table[i^2, {i, 100}], j], {j, 100}]]

enter image description here

An equivalent code to the previous one:

ListLinePlot[
 Table[First[Part[IntegerDigits[Table[i^2, {i, 100}]], j]], {j, 100}]]

There are other elegant solutions of this problem, e.g.:

First /@ IntegerDigits@Table[i^2, {i, 100}] // ListLinePlot

enter image description here

But, the last code uses the function Map[] (/@) which is supposedly not known in Chapter 6 of the book.

About Exercise 6.8:

Make a list line plot of the number of digits in each of the first 100 squares.

One of the possible solutions:

ListLinePlot[Table[Length[IntegerDigits[i^2]], {i, 1, 100}]]

enter image description here

Another solution:

ListLinePlot[
 Table[Length[IntegerDigits[Range[100]^2][[i]]], {i, 100}]]

enter image description here

I would use Table and Length like this:

list = IntegerDigits[Range[100]^2];
Table[Length[list[[i]]], {i, 1, Length[list]}]

I'm sure that there are other ways, but this one is pretty straightforward.

POSTED BY: Tim Mayes
Posted 9 years ago
POSTED BY: Bill Simpson

Thank you, I was also very stuck on this one.

POSTED BY: Camille Driscoll
Posted 9 years ago
POSTED BY: D P
Posted 9 years ago
POSTED BY: Jawad Mansoor
ListLinePlot@Table[IntegerDigits[i^2][[1]], {i, 100}]

Other variations on the same subject of Exercise 6.10:

ListLinePlot[IntegerDigits[Range[100]^2][[;; , 1]]]
IntegerDigits[Range[100]^2][[;; , 1]] // ListLinePlot
ListLinePlot[First /@ IntegerDigits[Range[100]^2]]
First /@ IntegerDigits[Range[100]^2] // ListLinePlot
Table[IntegerDigits[i^2][[1]], {i, 100}] // ListLinePlot

From each row, select the first element.

That's interesting. I didn't understand at first how this could work, but

IntegerDigits[Range[100]^2] // TableForm

makes it clear. From all rows, select the first column.

POSTED BY: Arno Bosse

A solution without Table[]:

ListLinePlot[IntegerDigits[Range[100]^2][[All, 1]]]

Nice solution!

Posted 9 years ago
POSTED BY: D P
Posted 9 years ago

Hi Bill, thanks for your reply.

I think that I am expected to use functions that have been taught in the previous chapters ie. Table, Count, IntegerDigits, Length, Range. Map has not been taught yet.

Essentially, what I need to do is to Count the number of elements in each element of the list. I know that there are 100 elements in the list, each consisting of 1 or more elements.

So I need something like: Count[IntegerDigits[Table[n^2, {n, 100}]]] , which doesn't quite work. I strongly suspect the command is a combination of Count(or Length), IntegerDigits, Range, and perhaps Table.

POSTED BY: D P
