Here is the frame version of video saved as .mov. You can change step size of Table in this case 30. If you want fast movie, increase stepsize.

video = Table[
   Graphics3D[ {{GrayLevel[.7], Line[space[[1 ;; t]]]}, {Red,
      Arrowheads[.07], Arrow[Tube[{{0, 0, 0}, space[[t]]}, 0.01]]}},
    Axes -> True,
    AxesStyle -> Directive[FontSize -> 17, FontFamily -> "Helvetica"],
     AxesLabel -> {"x", "y", "z"}, BoxRatios -> {1, 1, 1},
    ImageSize -> 400, PlotRange -> 1, SphericalRegion -> True,
    Boxed -> False, ViewPoint -> {0, -2, 1}], {t, 1, Length@data, 30}];

Export["test.mov", video]

Attachments:

Hi Abir,

Your attached "My_vdo.mov" has some other issues apart from the animation playback rate. About half a dozen frames in it are not rendered properly which results in a distracting 'flashing' experience. When I export the animation to QuickTime OSX (MMA v11.3) I don't see these problems. But if I export it as an AVI file I see the exact same issues on OSX. That suggests a bug in how MMA creates AVI files on both platforms. The way to work around that is to specify a different video codec:

Export["test.mov", %, "VideoEncoding" -> "MPEG-4 Video"]

As an aside, if you just export the animation to QuickTime on either platform without further parameters, MMA still defaults to using the long deprecated Apple Cinepak codec. By now that's a bug.

Neil mentioned that Export doesn't support the animation duration option. And it's true that if you look for it in the current documentation for Export, it's not listed there (another aside: why doesn't every function document all of its options?). But if you look-up "AnimationDuration" you'll see that it is briefly mentioned as an option for FLV and SWF though not for AVI or QT. Regardless, it is still possible to set this as an option for Export for QT and AVI as well, with values in seconds. You can now use this together with a reduced frame rate as a quick and dirty way to 'stretch out' your animation a little:

Export["test.mov", %, "VideoEncoding" -> "MPEG-4 Video", "AnimationDuration" -> 20, "FrameRate" -> 10]

However, I'm sure Neil's solution will be the better one. George also mentioned exporting the animation as a sequence of image files using "VideoFrames" and then employing an external tool like ffmpeg to turn these into a video again. In theory, this should be possible by exporting it as an animated GIF as well using the "DisplayDurations" option, but in my quick experiments, this didn't affect the overall duration or the perceived playing rate of the animation.

Abir,

I asked this as a question to Tech Support a year ago and they gave me a better explanation of the issue. I found the old email and this may help you:

I understand Export function seems to ignore the duration option in Animate function.  In Mathematica, Animate[expr, {u, umin, umax}] function does not generate frames in Kernel. Instead, the Mathematica frontend will generate the frames but other functions, like Export[], cannot use these frames. When Export takes Animate as input, it will generate frames for 4 seconds and export it. If you need to specify the duration of the exported, please manually generate all the frames, like:

In[62]:= time = 10; fps = 24; da = 0.1; a0 = da;
In[63]:= frames = Table[Plot[Sin[a x], {x, -Pi, Pi}, PlotRange -> {-Pi, Pi}], {a, a0, 0.1*time*fps, da}];
In[64]:= Export["test.mov", frames, "FrameRate" -> fps]
Out[64]= "test.mov"

Meanwhile, I understand it will be better if function Export can read the "Duration" option when the input is Animate and works as you expected. Therefore, I filed a suggestion to the development team, raising this idea to them. Thank you again for bringing this question to us and help us improving Mathematica.

Hi Mikayel,

Thanks for replying. I am using the version 11.2 on Windows as I stated earlier. I have attached the video to the previous message also (named as My_vdo). The code is:

alvar = Flatten[ Import["C:\\Users\\Abir\\Documents\\code\\forplot.mat"]];
mx = Take[alvar, {1, Length[alvar]/4}];
my = Take[alvar, {Length[alvar]/4 + 1, Length[alvar]/2}];
mz = Take[alvar, {Length[alvar]/2 + 1, Length[alvar]/4 * 3}];
time = Take[alvar, {Length[alvar]/4* 3 + 1, Length[alvar]}];
mmm = Thread[{mx, my, mz}];
data = Thread[{time, mx, my, mz}];
space = data[[All, 2 ;; 4]];

Manipulate[

 Graphics3D[
  Dynamic@{{GrayLevel[.7], Line[space[[1 ;; t]]]}, {Red, Arrowheads[.07], Arrow[Tube[{{0, 0, 0}, space[[t]]}, 0.01]]}},
  Axes -> True, AxesStyle -> Directive[FontSize -> 17, FontFamily -> "Helvetica"],
  AxesLabel -> {"x", "y", "z"}, BoxRatios -> {1, 1, 1},
  ImageSize -> 400, PlotRange -> 1, SphericalRegion -> True,
  Boxed -> False, ViewPoint -> {0, -2, 1}],

 Row[{Control[{t, 1, Length[data], 1, Animator, ImageSize -> Small,
     AnimationRunning -> True, AnimationRepetitions -> 1,
     AnimationRate -> 500}], Spacer[10],
   Dynamic["second"       data[[t, 1]]]}]
 ]

Export["test.mov", %]

This code takes a .mat file (forplot.mat) as input. The mat file is also attached. It has data for three axes and time.

I'll look forward to you or any other person's reply in this regard. I'll much appreciate that.

Best,

Abir
